Trunkline wall outlet for CATV
BK trunk line outlet up to 1006 MHz, 2 ports with return path, TV attenuation ~12 dB, through loss ~1 dB, Class A+10 dB (LTE safe), 55 mm box, Vodafone certified.
GUT 152
Specification
| Application | BK outlet |
|---|
| Order number | 00541851 |
|---|---|
| EAN-Code | 4026187410896 |
Product Details
- for reception of terrestrial radio and TV programmes up to 1006 MHz
- with 2 outputs and return path
- Screw and claw fastening
- Mounting in 55 mm wall sockets
- improved EMC properties through compliance with class A + 10 dB (LTE safe)
- simple, fast and safe clamping technique (even with different Ø)
- for standard coaxial and mini coaxial cables
- Cable kink protection due to rounded housing shape
- excellent electrical values
- TV connection attenuation approx. 12 dB
- Transmission loss approx. 1 dB
- Vodafone certified
- BK trunk line junction box
Download Details
-
Datenblatt GUT 152 DE pdf · 2mb
-
Produkt-Newsflyer GUT LTE safe DE pdf · 2mb
